Charging station for Tesla (up to 11kW)

  • Up to 11.1 kW
  • Residual Current Detection (DC 6mA)
  • Automatically optimized charging power
  • TESLA – Opens charging port remotely
  • TESLA – Unlocks charger
  • Custom sized cable
  • Designed & manufactured in EU

from 853,05

705,00  (ex. VAT)

This private charging station is made to charge any vehicle in Mode 3 at maximum 11.1kW. Benefit from your personal wallbox at home or at work in order to charge electric vehicles or plug-in hybrid vehicles.

This smart charger gives additional comfort features to charge TESLA electric vehicles having Type 2 charging socket. As a matter of fact, it allows to remotely open the charge port of your Tesla and to unlock the charging plug when you stop charging. It is that easy.

Equipped with all necessary protections for European standards, this charging station includes a residual current device to protect user against potential continuous current leakage coming from the vehicle (DC 6mA). Thanks to that, you can simply connect this charging station to your power grid while being compliant with safety rules. This smart charging solution also has overheating and overcurrent protections.

This enhanced charging solution allows user to set charging current. It can also monitor available power from your power grid and automatically adjust charging power so that main fuse is not operated with optional dynamic power control.

Designed for external use, this EV charging station takes advantage of a robust and solid conception. Its use has been greatly simplified so that it is convenient for users.

Cable used is ultra resistant. Made in Germany, it is extremely lightweight and flexible, even at cold temperatures.

This wallbox is universal. It is compatible with any EV or PHEV from any brand or manufacturer having Type 2 charging socket which is European standard.

In addition to that, this charging station is designed and manufactured within the European Union. It complies with all mandatory rules and standards that are essential for your safety.

Datasheet

Cable with connector
Type 2 Plug 300x279 - Charging station for Tesla (up to 11kW)
Type 2 (European standard)
Charging specifications
Max charging powerfrom 4.2 kW to 11.1 kW
from 1.4 kW to 3.7 kW (if single-phase)
Start-upPlug & charge
Charging modeMode 3
Rated voltage400V
Adjustable max. charging current6A / 8A / 10A / 13A / 16A
Charging current selectionManual
Automated (Dynamic power control option)
Features for TESLA vehicles
Remote opening of charging portYes
Unlocking charging plugYes
Charge hybrid or electric vehicle from other manufacturersYes
Protections
Protection ratingIP54 (rain resistant)
Shuts down in case of DC power leakYes (DC 6mA)
Shuts down in case of over-currentYes (10kA circuit breaker)
Overheating handlingYes (automated)
Ambient conditions of use
Temperature range-30°C to +50°C
Average temperature for 24 hoursunder 35°C
Storage temperature-40°C to +70°C
max. Humidity95 %
max. Altitude2000 m
Cable characteristics
Premium qualityLightweight and flexible
LengthUp to 20m on request
Enhanced resistance toOrganic aggression’s (oil, dust, water, lubricants, etc.)
Torsion, abrasion, corrosion, flames, UVs
OriginGermany
Other specifications
Weight (5m cable)~ 8 Kg
Size (HxWxD)Box: 30 x 20 x 12 cm
Front plate: 34 x 24 cm
User reportingLED
Elements reportedCharging status
Errors from vehicle, environment, charger, etc.
Color (cable and connector)Black (or Orange)
Power supplyThree-phase alternating current with neutral (AC)
Voltage range270V to 470V (50/60Hz)
Certifications
ConformityCE certified
StandardsIEC 61851
IEC 62196
OriginMade in EU

Compatible vehicles

This charger is compatible with any plug-in hybrid or electric vehicle having Type 2 charging socket. However, it is specifically designed for EU type of TESLA cars (Type 2 charging connector) because of the special features included that makes operations as easy as using Tesla Superchargers (SUC):

  • Tesla Model 3
  • Tesla Model S
  • Tesla Model X
  • Tesla Model Y
  • Any vehicle with Type 2 charging socket (European standard)

Lead time: Expect a couple days before shipping (custom-made product)

Scope of delivery:

  • 1 x Charging station for electric vehicles

Files to download after shipment of the charging station:

  • User manual (in English)
  • Quick installation guide (in English)
  • Note: the wall holder for the Type 2 plug, shown on some of the  pictures, is  separately available here
Smart Charge Control

Without, Smartphone app + wired dynamic power management, Wireless dynamic power management, Smartphone app

Cable length

5 m, 5 m [in spiral], 6 m, 7 m, 8 m, 10 m, 12 m, 15 m, 20 m

Cable and plug color

Black, Orange

Access control

Without, By remote control, By RFID card
